Vibration Sensor (Accelerometer)
MEMS vibration sensor with magnetic mount and 5-meter cable. Compatible with all Balanset models.
Vibration Sensor — MEMS Accelerometer for Balanset
Replacement or spare vibration sensor for Balanset-1A, Balanset-4, and Balanset-AR. Each Balanset unit uses two vibration sensors (one per measurement channel). This listing is for a single sensor.
Specifications
- Type: MEMS accelerometer
- Frequency range: 5–1000 Hz
- Vibration velocity range: 0.02–80 mm/s RMS
- Cable length: 5 m (shielded)
- Connector: Plugs into the X1 or X2 sensor input on the Balanset unit
- Mounting: Magnetic base (built-in) or M4 threaded stud
Installation
Mount the sensor on a solid, non-rotating part of the machine housing — ideally on or near the bearing support. Use the built-in magnetic base for quick attachment to ferrous surfaces, or the M4 threaded stud for permanent or non-magnetic installations. The sensor axis should be perpendicular to the shaft (radial measurement).
Related Products
Magnetic Stand
Articulated magnetic stand for mounting the Balanset laser tachometer. Strong magnetic base, flexible arm, universal clamp.
Reflective Tape
